AKW Bidet Collection

AKW Back-to-Wall Bidet

Product Details

Offering a modern, discreet and Doc M compliant solution for wash/dry toileting, the Back-to-Wall Bidet can be installed with a concealed cistern, with AKW Bathroom Furniture, or with a low-level cistern.

The Back-to-Wall Bidet is comprised of two products which are supplied in one pack:

  • AKW Bottom-Entry Bidet with Consilio Seat & Lid which benefits from multiple adjustable wash/dry settings as well as useful care features
  • Navlin Doc M Raised-Height Back-to-Wall Pan for Bottom-Entry Bidet which conceals bidet pipework for a modest finish

Compatible cisterns, furniture and wash basins are available separately depending on your requirements.

Warranty & Approvals

  • 2-year warranty on AKW Bidet (Up to 5 years with our extended warranty options)
  • 10-year warranty on flush fittings
  • Lifetime warranty on ceramic
  • Pan conforms to BS EN 997
  • Electrical items compliant with BS EN 60335-1
  • AKW are self-certifying and supplying approved flush fittings in line with current UK water regulations for compliance purposes

Product Description

Features & Benefits – WC

  • Raised-height toilet pan makes it easier for less mobile users to lower/rise from the toilet
  • Rear holes in toilet pan conceal AKW Bidet pipework for an enhanced cosmetic finish and reduction of hazards in the event of a trip or fall
  • Rimless toilet pan with direct flushing technique offers improved hygiene by reducing the build-up of bacteria and making cleaning easier
  • Two-point, side-entry floor fixings reduce build-up of dust/bacteria, are easier to clean, and come with white cosmetic caps to prevent rusting
  • Rounded edges and corners reduce the risk of injury in the event of a trip or fall
  • Toilet pan can support up to 60st (400kg); bidet seat can support a maximum load of 23.5st (150kg)
  • Contemporary design is compatible with Navlin and Navlin Doc M wash basins for a complete bathroom suite
  • Components individually packaged in recyclable materials to prevent damage during transit

Cistern Options

  • Can be installed with a concealed cistern for a streamlined aesthetic that hides any unsightly pipework
  • Compatible with AKW bathroom furniture; WC units include a Dudley Miniflo Cistern and recessed flush button
  • Can be installed as a low-level WC with the addition of a low-level cistern, flush pipe, and optional padded back rest (available in contrasting colours)
  • Low-level cistern offers choice of raised push button or non-handed spatula lever flush, both of which can be easily operated by hand, closed fist, or elbow
  • Optional sensor flush valve offers contact-free flush operation and is available separately; this must be ordered alongside the Navlin Low-Level
    Cistern with Raised Push Button Flush and installed in place of the button flush mechanism/ valve
  • Low-level cisterns with lever or raised push button flush mechanisms offer full (6 litre) and reduced flush options for increased performance and water efficiency

Technical Specification – WC

  • BS EN 997 approved toilet pan for guaranteed flush performance
  • Bottom inlet water connection simplifies pipework
  • Horizontal waste connection for easy installation and maintenance
  • Suitable for installation in front of solid/dry wall construction, with AKW Bathroom Furniture, or as a low-level WC
  • Supplied with relevant fixing kits as standard

Features & Benefits – AKW Bidet

  • Adjustable spray control offers thorough cleaning where and how it is needed
  • Instantaneous 1750W water heater offers a steady flow with no reheating period in between washes, and a choice of temperature settings
  • Powerful 350W dryer with settings that can be tailored to specific needs
  • Remote control provides users with full function control via a handheld, ergonomic remote, which is easy to use and supports carers with maximising user dignity
  • Self-cleaning function ensures the spray arm nozzle and surrounding area are hygienic
  • Night light helps those with visual impairment or dementia locate the toilet in the dark or dimly lit conditions, helping to alleviate the risk of confusion
  • Quiet and efficient operation promotes user dignity while providing a reliable experience
  • Integral seat sensor prevents accidental usage by ensuring activation only occurs when the seat is in use
  • Lid and seat lift assist with front moulded grips on the lid and contrasting side tabs for easy lifting, which are more hygienic and supports those with  limited dexterity
  • Quick-release seat and lid allows you to adapt the bidet for various care needs, and makes cleaning easier
  • Soft-close seat and lid is slower, quieter, and therefore safer for users, especially children
  • Seat lugs provide discreet stability when side transferring from a chair or commode
  • Strong load limit of 23.5st (150kg) ensures the bidet is suitable for a wide variety of users
  • Consilio seat features a large aperture ideal for care environments; Ergonomic seat option can be ordered separately
  • Quick and easy for your plumber and/or electrician to install with no specialist tools or prior training required
  • Bottom-entry water supply with plumbing concealed within pan
  • Easy to clean, user-friendly design, which should require very little maintenance throughout the bidet’s lifetime
  • Low-pressure mode ensures the bidet continues working efficiently during periods of low pressure

Product Variations

AKW Back-to-Wall Bidet
Dudley Miniflo Cistern
Palm-Push Dual Flush Plate
Navlin Low-Level Cistern with Raised Push-Button Flush & Flush Pipe
Navlin Doc M Low-Level Cistern with Lever Flush & Flush Pipe
PU Padded Back Rest & Rail (Blue)
PU Padded Back Rest & Rail (Grey)
PU Padded Back Rest & Rail (White)
AKW Bidet 1-Year Extended Warranty
AKW Bidet 2-Year Extended Warranty
AKW Bidet 3-Year Extended Warranty

Specification Sheets

Bidet Pack Two Specification Sheet

AKW Bidet Brochure
